Vacuum HP/HIP/melting/heat treatment services
Matsurface Technologies Inc provides vacuum hot pressing (HP) service, hot isostatic pressing (HIP) service, vacuum heat treatment service, and vacuum melting service for customers need to develop customized alloy materials, ceramic materials, targets, casting densification, and other products with ultra high density.
Hot isostatic pressing (HIP):
Max temperature: 2000 ͦ C
Max pressure: 150MPa.
Max product dimension: 500mm in diameter x 1000mm.
Applications/services:
Manufacture ultra-high density products for powder metallurgy, aerospace and medical casting densification, diffusion bonding,
Materials can be densified:
- High melting point metals:W, Mo, Ni, Nb, Ta, Cr, V
- High melting point alloys: WTi, CrMo, TiAl, CrAl, CrAlSi, TiSi, TiAlSi
- Carbide: SiC, WC, VC, CrC, NbC, TiC, ZrC, BN
- Nitride: SiN, WN, VN, CrN, NbN, TiN, ZrN, BC
- Boride: TiB2, ZrB2, SiB, WB, VB, CrB2, NbB2
- Surfide: TiS2, Sb2S3, MoS2, WS2, ZrS2
Max temperature: 2000 ͦ C
Max pressure: 150MPa.
Max product dimension: 500mm in diameter x 1000mm.
Applications/services:
Manufacture ultra-high density products for powder metallurgy, aerospace and medical casting densification, diffusion bonding,
Materials can be densified:
- High melting point metals:W, Mo, Ni, Nb, Ta, Cr, V
- High melting point alloys: WTi, CrMo, TiAl, CrAl, CrAlSi, TiSi, TiAlSi
- Carbide: SiC, WC, VC, CrC, NbC, TiC, ZrC, BN
- Nitride: SiN, WN, VN, CrN, NbN, TiN, ZrN, BC
- Boride: TiB2, ZrB2, SiB, WB, VB, CrB2, NbB2
- Surfide: TiS2, Sb2S3, MoS2, WS2, ZrS2
Vacuum hot pressing (HP):
Max temperature: 2500 ͦ C
Max pressure: 500 ton.
Base vacuum: 1x10-3Pa.
Max product dimension: 500mm in diameter x 1500mm.
Applications/services:
Manufacture high density products for powder metallurgy and diffusion bonding.
Materials can be produced:
- High melting point metals:W, Mo, Ni, Nb, Ta, Cr, V
- High melting point alloys: WTi, CrMo, TiAl, CrAl, CrAlSi, TiSi, TiAlSi
- Carbide: SiC, WC, VC, CrC, NbC, TiC, ZrC, BN
- Nitride: SiN, WN, VN, CrN, NbN, TiN, ZrN, BC
- Boride: TiB2, ZrB2, SiB, WB, VB, CrB2, NbB2
- Surfide: TiS2, Sb2S3, MoS2, WS2, ZrS2
- Selenide: In2Se3, Sb2Se3, Cu2Se, WSe2，CdSe，PbSe, ZnSe， CuSe, CuSbSe2
- Telluride: CdTe， SbTe, PbTe, MnTe, ZnTe,
Max temperature: 2500 ͦ C
Max pressure: 500 ton.
Base vacuum: 1x10-3Pa.
Max product dimension: 500mm in diameter x 1500mm.
Applications/services:
Manufacture high density products for powder metallurgy and diffusion bonding.
Materials can be produced:
- High melting point metals:W, Mo, Ni, Nb, Ta, Cr, V
- High melting point alloys: WTi, CrMo, TiAl, CrAl, CrAlSi, TiSi, TiAlSi
- Carbide: SiC, WC, VC, CrC, NbC, TiC, ZrC, BN
- Nitride: SiN, WN, VN, CrN, NbN, TiN, ZrN, BC
- Boride: TiB2, ZrB2, SiB, WB, VB, CrB2, NbB2
- Surfide: TiS2, Sb2S3, MoS2, WS2, ZrS2
- Selenide: In2Se3, Sb2Se3, Cu2Se, WSe2，CdSe，PbSe, ZnSe， CuSe, CuSbSe2
- Telluride: CdTe， SbTe, PbTe, MnTe, ZnTe,
Vacuum melting/heat treatment:
Max temperature: 1700 ͦ C
Max power: 150kW.Base vacuum: 6x10-3Pa.
Ingot weight: 0.5-150kg.
Applications/services:
Manufacture customized alloy products:
TiAl, TiSi, AlSi, TiAlSi, Mg2Si, Ti alloy, Al alloy, Mg alloy, Silicate, sulfide, special steel, intermatic alloys.
Max temperature: 1700 ͦ C
Max power: 150kW.Base vacuum: 6x10-3Pa.
Ingot weight: 0.5-150kg.
Applications/services:
Manufacture customized alloy products:
TiAl, TiSi, AlSi, TiAlSi, Mg2Si, Ti alloy, Al alloy, Mg alloy, Silicate, sulfide, special steel, intermatic alloys.
